Head height: 1080MM
Eye flow rate: greater than 11.4 L/min.
Flow rate: greater than 75.7 L/min.
Inlet size: 1-1/4 external thread.
Outlet size: 1-1/4 external thread.
Power supply: 220V/AC / 1PH / 50HZ
Explosion-proof grade: Exd IIBT6
Protection grade: IP65
Power: 25W/m
Total power: 140W
The gross weight: 65KG.
Net weight: 53KG.
Size: L * W * H = 2550 * 850 * 380mm.
Product size: L * W * H = 450 * 900 * 2450mm.
Use medium: it meets the standard of health standard.
Main material: special SS304 stainless steel conforming to national standard.
It is more corrosive to acid, alkali, salt and oil chemicals than the non-acid passivated SS304.
All the castings are made of silica sol technology, which will not have the defects of sand eye or stomata, which are higher in density and strength and longer in service life than sand casting process.
The way to wash eyes switch: manual.
When used, it is only needed to push the valve gently. The clean water comes out automatically from the nozzle, and the spray head is equipped with dust cover. When used, it can be automatically washed away with the flow of water.
After the shut-eye switch is opened, the non-man will operate and will not shut automatically. Please turn off the switch and reset the dust cover when used.
For the characteristics of the shower switch: use the heavy three – plate switch to pull down the drenching bar, the shower switch is opened, and the pull rod is pushed up and the shower switch is closed.
The flush switch handle is closed up 45 degrees, and the bottom 45 degrees is open.
Low eye nozzle: eye nozzle built-in multi-layer filter, effectively filter the impurities in water, the water flow into a foamy water, effectively prevent the impurities in water, or to the injured eye due to water flow ultra secondary damage nerve and the injured area.
The filter screen is easy to remove, easy to clean and easy to maintain.
